Vibration & Shock Testing for Electronics & Embedded Systems
Vibration and shock testing for electronics and embedded systems confirms a design decision made weeks earlier, at the PCB layout and mounting stage, not on the shaker table. A test campaign can catch a flaw, but it can't fix a board that was never built to survive its mechanical environment.
Measured impact on mechanical survivability
Component placement, PCB stack-up, connector selection, and enclosure mounting decide whether an assembly holds up under random vibration, shock, and resonance long before any unit reaches a lab. We design electronics and embedded systems to withstand vibration and shock as part of the hardware development process, then plan and oversee the test campaigns that confirm it.
How we design electronics that survive vibration and shock
Two disciplines work together here: the mechanical design decisions made before a board exists, and the test campaign that later confirms those decisions hold up.
Designing for vibration before the first prototype
- Frequency response analysis of the PCB and its mounting, a form of dynamics testing run in simulation before any physical vibration testing begins, finds natural frequencies that could coincide with excitation sources on the platform
- Where a resonance sits too close to the operating range, we adjust standoff placement, stiffen the board, or move mounting points, rather than leave it for the enclosure to damp out
- Connectors, transformers, and other heavy parts on unsupported PCB spans get reinforced or relocated during layout, since they're usually first to fail under random vibration
- Cable harnesses get strain relief and locking connectors so a shock event doesn't disconnect a signal path that passed every bench test
- When a physical test is planned, we design the custom fixturing, matching the production mounting so results reflect the actual installed configuration rather than a simplified lab setup
Planning and overseeing the test campaign
- Profile selection starts with the platform's actual duty cycle and the standard that applies to it, not a generic worst case
- We define the test sequence, including combined environmental testing where temperature cycling, vibration, and shock run against the same unit
- We coordinate directly with the accredited lab performing the physical test
- Test reports are reviewed against the original design assumptions, and any deviation feeds back into the next design revision
.avif)
What defines a vibration-tolerant assembly
A vibration-tolerant assembly holds up under real operating conditions, clears certification without late surprises, and performs the same way on unit one thousand as it did on the qualification sample.
Profiles are built from the platform's actual operating environment, not only the standard's minimum levels, so results reflect what the assembly will genuinely encounter in service.
Structural weaknesses surface and get corrected before formal certification testing, when a fix still costs a layout change instead of a missed program milestone.
Design and fixture decisions carry through to production, so every unit shipped meets the same durability and structural integrity standard as the unit that passed qualification, supporting the product reliability and customer satisfaction the program was built around.
In-house scope vs. accredited laboratory
Qualification for vibration and shock survivability splits cleanly between two parties: the design work that determines whether an assembly will pass, and the physical test that confirms it did.
What InTechHouse does in-house
What an accredited laboratory does
Vibration and shock profile types and when each applies
Standard selection depends on the platform. Airborne electronics are typically qualified against RTCA DO-160, Section 8 for vibration and Section 7 for operational shock and crash safety. Military and defense hardware is typically tested to MIL-STD-810, Method 514 for vibration and Method 516 for shock. Commercial and industrial electronics are frequently qualified against IEC 60068-2-6 for sinusoidal vibration and IEC 60068-2-27 for shock. The applicable standard gets selected during the design phase, not after a prototype is built.
A single frequency swept across a range at constant or stepped amplitude, used to identify resonances before a full qualification run.
Locates natural frequencies, then holds the assembly at each one to check for degradation over time.
Applies energy across a broad frequency band simultaneously, closer to most transport and operational environments than a single sine tone.
Overlays a discrete sine component, typically a rotating source such as a motor or rotor, onto a random background; common in vehicle and rotorcraft testing.
A short, high-energy sinusoidal pulse used to verify structural strength against a defined load.
A single defined pulse shape, such as half-sine or terminal sawtooth, simulating a mechanical event like a drop or impact.
A shock event defined by its shock response spectrum rather than one pulse shape, used where the real event is too complex for a classical waveform.
Typical failure modes and the design fixes that prevent them
The same handful of failure modes show up across most vibration and shock campaigns. Each one traces back to a specific design decision, not a manufacturing defect, and each has a fix that costs far less applied before the test than after it.
Symptom: intermittent failures appear during or after a random vibration run, often localized to one board corner. Mechanism: repeated flexing at a joint carrying a component with mass disproportionate to its pad area builds up fatigue cracks.
Fix: add mechanical support, such as an adhesive stake or bracket, or move the component closer to a support point during layout.
Symptom: signal dropout coincides with a shock pulse rather than developing gradually. Mechanism: the shock loading briefly exceeds the connector's retention force.
Fix: specify a locking connector variant and add strain relief on the cable side of the mating point.
Symptom: performance degrades, or a fault appears only under load, with no visible break. Mechanism: an unsupported board span flexes beyond the laminate's fatigue limit over repeated cycles.
Fix: add mounting points or stiffening ribs to shorten the span and raise the assembly's natural frequency.
Symptom: the board fails at a lower input level than its own resonance would predict. Mechanism: the enclosure's natural frequency sits close to the board's, and the two amplify each other instead of one damping the other.
Fix: separate the two resonances at the design stage, by stiffening the enclosure or adjusting board mounting stiffness.
